| Parameter |
L55-B5 |
| Total power(kw) |
162 |
| Operating weight(kg) |
17600/19000(*) |
| Bucket capacity(m³) |
3.6/4.5(*) |
| External dimensions(mm) |
8210 x 3020 x 3450/8200 x 3020 x 3520(*) |
| Rated loading capacity(t) |
5 |
| Maximum dumping height(mm) |
2910/2920(*) |
| Dumping distance(mm) |
1290/1260(*) |
| Subtotal(s) |
10.5 |
| Wheelbase(mm) |
3270/3250(*) |
| Maximum speed(km/h) |
fwd:38,rev:15 |
| Emissions (Indicated as per international standards) |
Tier 2 / Stage II |
| (*) |
*: The technical specifications on the left correspond to a wheel loader with a 3.6m³ bucket / The technical specifications on the right correspond to a wheel loader with a 4.5m³ bucket. |
