| Parameter | DGL530-C |
|---|---|
| Engine power(KW) | 390 |
| Milling and mixing width(mm) | 2310 |
| Operating Weight(Kg) | 22740 |
| External dimensions (length × width × height)mm | 9606×3270×3520 |
| Engine model | WP13G530 |
| Milling and mixing depth(mm) | 400 |
| Working speed(m/min) | 0~48 |
| Travel speed(m/min) | 0~25 |
| Wheelbase(mm) | 5725 |
| Track width(mm) | Front:2250 Rear:2200 |
| Emission | Eu stage IIIA |
