| Parameter | DL300-C3 |
|---|---|
| Engine power/speed(kW/rpm) | 228/1900 |
| Operating mass(kg) | 29700 |
| Bucket capacity(m³) | 3.2 |
| Machine external dimensions(mm) | 7345x2980x3510 |
| Engine | WEICHAI WP12 |
| Track center distance(mm) | 2160 |
| Track shoe width(mm) | 660/830 |
| Ground contact length(mm) | 2945 |
| Ripper type | Three-tooth |
| Ripper penetration depth(mm) | 397 |
| Emissions (Indicated as per international standards) | EU stageⅢA |
