| Parameter | SK90A-C1 |
|---|---|
| Machine weight(kg) | 90000 |
| Load capacity(kg) | 60000 |
| Engine power speed(kW/rpm) | 338/2100 |
| External dimensions(mm) | 8950×3550×4150 |
| Axle load(t) | 20/35/35 |
| Transmission | FC6A210 |
| Fuel tank capacity(L) | 600 |
| Tire | 14.00-25 |
| Drive axle | 35T,planetary two-stage central and wheel-side reducer with an inter-axle differential lock |
| Emissions (Indicated as per international standards) | Eu stage IIIA |
